CT Imaging Texture Analysis: Evaluation of Variability Sources in the Different Steps of Radiomic Workflow

2 Mins
Radiology
Authors:
*Francesca Calderoni,1 Cristina De Mattia,1 Francesco Rizzetto,2 Paola Enrica Colombo,1 Angelo Vanzulli,2,3 Alberto Torresin1

1. Medical Physics Department, ASST GOM Niguarda, Milan, Italy
2. Radiology Department, ASST GOM Niguarda, Milan, Italy
3. Department of Oncology and Hemato-oncology, University of Milan, Milan, Italy
*Correspondence to [email protected]

Disclosure:

The authors have declared no conflicts of interest.

Acknowledgements:

The authors wish to thank the physics, radiology, and radiotherapy departments of Istituto Scientifico Romagnolo per lo Studio e la Cura dei Tumori (IRST) IRCCS, Meldola, Italy, and “Santa Maria delle Croci” Hospital, Ravenna, Italy, for the availability of staff and equipment.

Citation:
EMJ Radiol. ;1[1]:26-28. Abstract Review No. AR1.
Keywords:
CT imaging, features variability, radiomic workflow, texture analysis.

Each article is made available under the terms of the Creative Commons Attribution-Non Commercial 4.0 License.

BACKGROUND AND AIM

One of the main issues in radiomics is the heterogeneity of data and methods of analysis because each step of a radiomic study hides pitfalls that, in the end, can combine and lead to the failure of the whole process.1-3 Several works can be found in the literature concerning single sources of variability, but they do not provide conclusions on the whole workflow. 4-6 The aim of this work was to analyse the main sources of textural radiomic features (RF) variability in the different steps of the radiomic workflow,1 to quantify its extent, and evaluate possible recommendations for its reduction.

MATERIALS AND METHOD

For each step of the radiomic workflow, potential sources of variability concerning CT imaging were analysed (Figure 1).

Figure 1: Analysed variability sources within the different steps of the radiomic workflow.

Most of the analyses were performed on phantom acquisitions,1 while patients’ images2 were used to test some parameters considered not significant on a phantom.

The authors focussed on intrascanner repeatability, interscanner reproducibility, tube voltage, and automated workload in the acquisition step; slice thickness, interval, algorithm, and kernel for the reconstruction step; inter-reader and interformat variability in segmentation; and voxel resampling and parameters for features extraction.

The analyses were performed on Catphan® (The Phantom Laboratory, Salem, New York, USA) acquisitions and patients’ images. A wide set of scanner manufacturers and models was considered involving different centres. The software used for segmentation and features extraction were IntelliSpace Portal 8.0 (Philips Medical Systems, Amsterdam, the Netherlands), 3DSlicer,7 and IBEX.8

The effect of the different sources of variability on RF was expressed in terms of relative standard deviation (RSD) or relative discrepancy.

RESULTS

In the imaging acquisition step, intrascanner repeatability, interscanner reproducibility, and tube voltage caused high RF variability, with RSD ranging from 0% to 800% and a mean value of 30%. On the other hand, the automated workload was demonstrated to not strongly affect RF values.

Regarding imaging reconstruction, the most crucial parameters were algorithm and kernel
with RF variations, in terms of relative discrepancy and RSD, up to 600% and 400% and mean
values of 50% and 20%, respectively.

The inter-reader variation in contouring was overall the largest source of variability, with mean and maximum values of 60% and 1,000%, respectively.

In the RF extraction step, the interslice resampling appeared not a useful solution, while the choice of the feature category parameters was the most critical point to standardise in the radiomic workflow. In addition, changes in these values unpredictably affect the variabilities caused by the other parameters.

Overall, seven textural RF (out of 32) showed a variability within the 10% for all the analysed issues, and 19 RF did not exceed the 20% either way.

CONCLUSION

A phantom study is preparatory to determine an optimal workflow that maximises RF predictivity on patients. Some variability sources can be limited or removed through standardisation processes, especially for the imaging reconstruction and RF extraction steps. Nevertheless, the issues due to acquisition and inter-reader variability remain. Regarding the acquisition step, the main effect on RF stability is attributable to reproducibility, which at present is unavoidable in multicentric studies. On the other hand, inter-reader variability might be limited through automatic segmentation tools. Finally, variability sources and the different behaviour of RF must be evaluated depending on the trial characteristics in order to find a compromise between stability and predictivity.

References
Lambin P et al. Radiomics: the bridge between medical imaging and personalized medicine. Nat Rev Clin Oncol. 2017;14:749-62. Larue RTHM et al. Quantitative radiomics studies for tissue characterization: a review of technology and methodological procedures. Br J Radiol. 2017;90(1070):20160665. Yip SSF et al. Applications and limitations of radiomics. Phys Med Biol. 2016;61(13):R150-66. Berenguer R et al. Radiomics of CT features may be nonreproducible and redundant: influence of CT acquisition parameters. Radiology. 2018;288(2):407-15. Varghese BA et al. Reliability of CT-based texture features: phantom study. J Appl Clin Med Phys. 2019;20(8):155-63. Ger RB et al. Comprehensive investigation on controlling for CT imaging variabilities in radiomics studies. Sci Rep. 2018;8(1):13047. Federov A et al. 3D Slicer as an image computing platform for the Quantitative Imaging Network. Magn Reson Imaging. 2012;30(9):1323-41. Zhang L et al. IBEX: An open infrastructure software platform to facilitate collaborative work in radiomics. Med Phys. 2015;42(3):1341-53.
